STEP 31: TIRE SWING
1: CENTER THE TIRE SWING SWIVEL ON THE CENTER DECK SUPPORT.
2: MARK THE LOCATION OF THE HOLES IN THE SWIVEL WITH A PENCIL, AND WITH A 3/8" DRILL BIT, DRILL HOLES
THROUGH THE CENTER DECK SUPPORT AND DECK BOARD.
3: USE A 5-1/2" CARRIAGE BOLT TO CLEAR OUT ANY DEBRIS LEFT OVER FROM DRILLING, MATE WITH A TORQUE
WASHER AND SET THE TORQUE WASHER ON TOP OF THE DECK WITH A HAMMER.
4: PLACE THE TIRE SWIVEL ON THE TWO CARRIAGE BOLTS, AND FASTEN WITH 3/8" LOCK NUTS WITH 3/8" WASHERS.
COVER ANY EXPOSED THREADS WITH BOLT CAPS.
5-1/2" CARRIAGE
BOLT
TORQUE WASHER
3/8" WASHER
3/8" LOCK NUT
TIRE SWIVEL
BOLT CAP
