Gorilla Playsets Sun Palace - Page 17

3/8 x 9"
CARRIAGE BOLT
QTY: 1
3/8 x 5-1/2"
CARRIAGE BOLT
QTY: 2
3/8 x 3-1/2"
CARRIAGE BOLT
QTY: 2
3/8 X 5"
HEX LAG SCREW
QTY: 14
3/8 X 3-1/2"
HEX LAG SCREW
QTY: 41
PLASTIC
BOLT CAP
QTY: 21
#2 SQUARE
DRILL BIT
QTY: 1
3/8 x 6-1/2"
CARRIAGE BOLT
QTY: 16
1
4
3
2
5
6
7
8
9
USE THE RULER TO THE RIGHT TO MEASURE YOUR BOLTS AND SCREWS. PICTURE VIEWS SHOWN
ABOVE ARE 1:1 SCALE AND CAN BE USED TO MATCH BOLT AND SCREW SIZES.
17
