1-800-637-9508 page 4
Step 3 - Adding top beams
Add the Short Double
Rivet Beams to the
top two key holes of each angle post
(refer to detail). Be sure all flanges are
up.
Hit the beam near the joints with a rub-
ber mallet to lock pieces together.
PRIMARY END ASSEMBLY WORK BENCH
Step 5 - Add-On Unit End Assembly.
Start by assembling two 36" Angle Post and two
Short Double Rivet Beams. The first Short
Double Rivet Beam must be assembled to the
top two keyholes of the Angle Post. The second
Short Double Rivet Beam must be assembled at
the 7
th
-8
th
keyhole from the bottom of the
Angle Post.
Repeat for the opposite end.
Hit the beam near the joints with a rubber mal-
let to lock pieces together.
ADD ON UNIT WORKBENCH
7th or 8th
keyhole
Step 4 - Adjustable Beams
Add
the two Short Double
Rivet Beams
with flange up to your desired heigth, and
drive the beams down with a rubber mal-
let.
