Before using the charger locate the voltage selector switch (li-ion chargers only) on
the back of the charger. Select either 115 volts or 230 volts depending on your
country of residence. Using the wrong voltage setting will permanenty damage the
charger and/or electrical components on the hybrid electric bicycle.
BATTERY ASSEMBLY
1. Use the matching charger.
2. Insert the round plug into the E-Bike first and then insert the charger plug into
the electrical socket.
3. A red light indicates the battery is charging.
4. A green light indicates the battery is fully charged.
5. The Key lock position will vary from model to model.
6. The battery is removable, the battery can be charged attached to the E-Bike or
pulled out and charged separately.
CHARGING THE BATTERY
1. When using the charger for the first time, carefully check whether the rated
output voltage of the charger is consistent with the battery voltage and check
whether the charger input voltage is consistent with the grid voltage.
2. When charging, first put the charger in a ventilated place, then insert the charger
output plug into the charging port. Plug the electrical power plug into the
100-240V 50/60Hz AC Power Supply. Be sure to keep the input plug in contact
with the AC outlet.
3. After charging, the input plug of the charger shall be pulled out first, and then
the output plug connected with E-Bike shall be pulled out. Do not leave the
charge plugged in.
Battery Information
27
