MAINTENANCE
NOTE: This meter is designed for minimum maintenance. Inspect meter and
components regularly for fuel leaks. Keep the meter exterior clean to help
identify leaks.
IMPORTANT: This fuel meter is designed, tested and approved for
use with thin viscosity petroleum fuels such as gasoline blends (up to
E15), diesel fuel blends (up to B20) and kerosene (see BEFORE YOU
BEGIN: Usage Requirements at front of manual). Use of the meter with
unauthorized fluids will void the warranty.
Clean Register and Nutator Assembly
1. Turn the system off and disconnect from power. Remove the coverplate
and O-ring, and inspect for damage (see Figure 1). If O-ring is
damaged, replace.
2. Remove (2) register screws and register from cover plate. Clean
register with a soft-bristled brush and solvent. If the register is very
dirty, compressed air may be used. Replace register.
3. Remove the gearplate and O-ring from the backshell, and inspect for
damage (see Figure 1). If O-ring is damaged, replace.
4. Remove (2) nutator assembly screws and nutator assembly from back
shell. Clean nutator assembly with a soft-bristled brush and solvent.
If the nutator assembly is very dirty, compressed air may be used.
Replace nutator assembly.
5. Coat the O-rings lightly with grease. Reinstall meter components.
Ensure the O-rings are properly seated and tighten securely.
