GPS1195 Auto Gate Manual Version 3
Terminal 7 – Free detector enable
Terminal 8 – Free detector enable
Terminal 9 – Close detector enable
Terminal 10 – Close detector enable
Terminal 11 – Down Limit switch NO input - Red
Terminal 12 - +24V – Black & Green Wire – Input common
Terminal 13 – Up Limit switch NO input - White
Terminal 14 - +24V – Input common
Terminal 15 – Safety Edge Input
Terminal 16 - +24V – Input common
Connector 3 (Relay Contact Outputs)
Terminal 1 – Lockout contact 1 – Common
Terminal 2 – Lockout contact 1 – Normally Closed
Terminal 3 – Lockout contact 1 – Normally Open
Terminal 4 – Lockout contact 2 – Common
Terminal 5 – Lockout contact 2 – Normally Closed
Terminal 6 – Lockout contact Normally Open
Terminal 7 – Free detector contact B
Terminal 8 – Free detector contact B
Terminal 9 – Close Detector – Contact B
Terminal 10 – Close Detector – Contact B
Terminal 11 – Arming Detector – Contact B
Page 8B
