GPS1195 Auto Gate Manual Version 3
Vehicle Loop Detector
The standard GPS vehicle detector is 120V. The standard version is designed to detect standard four
wheel Passenger Vehicles, Vans, Pickup trucks, Sport utility vehicles plus all other forms of traffic, like
motorcycles, RV’s, High bed trucks, Trailers, Construction vehicles, etc.
The standard detector found in all GPS Equipment is the LMA-1250HV from EDI – Failsafe
120vac/220vac
Pin Configuration
1 – AC Line
2 – AC Neutral
3 – Output B Relay – N.O
4 – No connection
5 – Output A Relay – Com
6 – Output A Relay – N.O
7 – Loop Input
8 – Loop Input
9 – Output B Relay – Com
10 – Output A Relay – N.C
11 – Output B Relay – N.C
