GPS1195 Auto Gate Manual Version 3
PLC Version 2 Controller Wiring Connections
Connector 1 (120Vac Line Voltage Connections)
Terminal 1 – Up Motor – Red Wire
Terminal 2 – Down Motor – Black Wire
Terminal 3 – 120Vac Neutral – White Wire
Terminal 4 – 120Vac Neutral – Traffic Light
Terminal 5 – Traffic Light Green or Red
Terminal 6 – Traffic Light Red or Green
Terminal 7 – 120Vac Line in – Black Wire
Terminal 8 – 120Vac Line in – Black Wire
Terminal 9 – 120Vac Neutral in – White Wire
Terminal 10 – 120V Neutral in – White Wire
Terminal 11 – Earth Ground – Green Wire
Terminal 12 – Earth Ground – Green Wire
Connector 2 (Inputs (24Vdc Low Voltage)
Terminal 1 – Pay Input – Vend 1 Input
Terminal 2 - +24V – Input Common
Terminal 3 – Not assigned
Terminal 4 - +24V – Input Common
Terminal 5 – Not assigned
Terminal 6 – Auto/Manual Input
