Coaxial Audio Output: Connecting a Stereo System
13
When connecting two products using an RCA Cable, match the colored ports with the
same colored connection. (Red to Red, White to White, and Yellow to Yellow)
1. Connect a 3.5mm - RCA Cable (not included) to the Coaxial Audio Output on the
unit and the coaxial audio input on a surround sound system.
2. Turn the unit on by adjusting the Power Button to the On position.
3. Change the stereo system to the correct audio input setting.
4. Audio played through the unit will now be heard on the connected television or stereo
system.
To connect video to a television when using the Coaxial Audio Output connection for
audio, connect the AV Output, or S-Video Output to a television.
