page 7
model
101
owner’s manual
Cable Diagrams
XLR Unbalanced Output Cable
12
3
SHIELD
HO
T
GROUND
(OPEN)
SHIELD
HO
T
GN
D
RING IS OPEN
TIP
RING
SLEEVE
PREAMP END
1/4” TRS Unbalanced Output Cable Termination
6VDC 800mA
GRACE DESIGN
BOUDLER, CO
MADE IN USA
BALANCED
OUTPUTS
FOR UNBALANCED
OUTPUT PIN 3 (RING)
MUST BE OPEN
PUSH
MIC
INPUT
microphone
instrument
tape machine DAW
mixer
Basic Wiring Diagram
