BEFORE USE
• Choose a good location and avoid placing the unit in direct sunlight or near any heat source.
• Avoid locations subject to vibrations, excessive dust, cold or moisture.
• Do not open the cabinet as this may result in electrical shock. If a foreign object is inserted accidentally contact your
dealer.
• When removing the power plug from the wall outlet, always pull directly on the plug and not the cord.
• Do not attempt to clean the unit with chemical solvents as this might damage the finishing. Use a clean, dry cloth.
• In order to completely turn off the unit, unplug the power cord from the wall outlet.
• Keep this manual in a safe place for future reference.
LOCATION OF PARTS
1. POWER SWITCH
FRONT VIEW
TOP VIEW
2. TONE ARM
3. SPEED CONTROL SWITCH
4. SECURITY HOOK
5. TONE ARM REST
6. TURNTABLE
7. TRANSPORTATION SCREW
(Large Silver Screw)
8. PLAY BUTTON
9. RETURN BUTTON
10. STOP BUTTON
11. USB JACK
12. LINE OUT
13. STYLUS (NEEDLE)
TURNTABLE SET UP
1. Connect the AC power cord to the an electrical outlet. The standard voltage is 120V-50Hz.
2. The silver transportation screw is required to protect the phonograph chassis during transportation. If the speed of your
phonograph seems slow or you hear a rubbing sound, adjust the screw with a coin to correct the balance of the turntable.
5
BACK VIEW
