Grace BiX User Manual

page 8
10 Specifications
GAIN RANGE
Line Output 0dB to +37dB
DI Output, Level: Line -29dB to +8dB
Boost 0dB to +12dB
THD+N 22Hz-22kHz BW
1kHz @ 0dB Gain +10dBu out < 0.002%
1kHz @ 20dB Gain +10dBu out < 0.002%
1kHz @ 36dB Gain +10dBu out < 0.005%
INTERMODULATION DISTORTION - SMPTE/DIN 4:1 7kHz/50Hz
@ 36dB Gain +10dBu out < 0.008%
FREQUENCY RESPONSE
Line output @ 20dB Gain -3dB 10Hz – 185kHz
DI output @ -9dB Gain, -3dB 10Hz – 40kHz
I/O IMPEDANCE
Instrument Input 10MΩ
Insert Input 200kΩ
Insert Output 150Ω
Line Output 150Ω
DI Output 150Ω
SIGNAL / PEAK LED METER
Green threshold -13dBu
Red threshold +12dBu
MAXIMUM INPUT LEVEL
Instrument Input +22dBu
Insert Return (0dB Boost) +22dBu
MAXIMUM OUTPUT LEVEL - 100k Ohm load, 0.1% THD
Line Output +22dBu
DI Output (Mic) -7dBu
Insert Output +22dBu
EQ
Gain +/-15dB
Low Frequency (Low Range) 100Hz
Low Frequency (High Range) 200Hz
High Frequency (Low Range) 2kHz
High Frequency (High Range) 4kHz
DYNAMIC RANGE 22Hz-22kHz BW
Minimum Gain, Line Out 129dB
Minimum Gain, DI Out 129dB
OUTPUT NOISE 22Hz-22kHz BW
Minimum Gain, Line Out -107dBu
Minimum Gain, DI Output < -120dBu
Maximum Gain, Line Out -78dBu
Maximum Gain, DI Out -106dBu
POWER
Connector 2.1mm Center Negative
Nominal Input Voltage 9VDC
Nominal Input Current 150mA
Input Voltage Range 6VDC – 12VDC
WEIGHT and DIMENSIONS
1.2lbs (0.55kg) H2.5” x W5.1” x D4.5” (H6.35cm x W13.0cm x D11.4cm)
