Graco 217314 - Dimensions

21307212
Dimensions
Model 244375: 3” (76.2 mm)
All Other Models: 4.94” (125.5 mm)
1.76” (44.7 mm)
1.8” (46 mm)
3/8 npsm female INLET
(3/8–19, ISO male, Model 243414 only)
3.65” (93 mm) DIA.
3/8 npt(f) OUTLET
(3/8–19, ISO female, Model 243414 only)
1/4 npt
GAUGE PORT
10.25”
(260 mm)
1/4 npt AIR INLET
(Model 214980 only)
3/8 npsm female ADAPTER OUTLET
(Models 217314 and 221118 only)
