308788 3
Parts List
Husky 1040 Model No. 240623, Series C
With BSP manifolds and Tri-Clamp adapters
Husky 1040 Model No. 240624, Series C
With bare BSP manifolds
Ref.
No. Part No. Description Qty
1 188838 HOUSING, center; alum. 1
2 188854 COVER, air valve; alum. 1
3 116344 SCREW, mach, hex flange hd;
M5 x 0.8; 12 mm (0.47 in.)
9
4{ 188618 GASKET, cover; SantopreneR 1
5 188855 CARRIAGE; aluminum 1
6{ 108730 O-RING; nitrile 1
7{ 188616 BLOCK, air valve; acetal 1
8 188615 PLATE, air valve; sst 1
9{ 188617 SEAL, valve plate; buna-N 1
10{ 112181 PACKING, u-cup; nitrile 2
11 188612 PISTON, actuator; acetal 2
12 188613 BEARING, piston; acetal 2
15 188611 BEARING, pin; acetal 2
16 188610 PIN, pilot; stainless steel 2
17{ 157628 O-RING; buna-N 2
18{ 188614 BLOCK, pilot; acetal 1
19 188609 BEARING, shaft; acetal 2
20 116343 SCREW, grounding 1
22 188603 GASKET, air cover; foam 2
23 188839 COVER, air; aluminum 2
24 188608 SHAFT, diaphragm; sst 1
25 115643 SCREW; M8 x 25;
25 mm (1 in.)
12
26 290045 PLATE, designation 1
27 188620 LABEL, identification 2
28 111183 RIVET 2
29 189989 LABEL, CE 1
Ref.
No. Part No. Description Qty
101 188860 COVER, fluid; sst 2
102 193421 MANIFOLD, inlet, BSP thread;
sst
1
103 193419 MANIFOLD, outlet, BSP
thread; sst
1
104 188607 PLATE, air side; aluminum 2
105 188960 PLATE, fluid side; sst 2
106 112178 SCREW; M8 x 1.25;
25 mm (1 in.)
24
107 189044 BOLT; M12 x 1.75;
35 mm (1.38 in.); sst
2
108* 104319 O-RING; PTFE 2
110Y 188621 LABEL, warning 1
114 112257 NUT, hex; M8 x 1.25; sst 8
115F
193427 ADAPTER, Tri-Clamp; 1.5 in.
Model 240623 only
2
116F
193422 GASKET; PTFE
Model 240623 only
2
117 115459 SPRING, compression 2
201* 188707 SEAT; 316 stainless steel 4
202* 109205 O-RING; PTFE 8
301* 112088 BALL; PTFE 4
401* 188606 DIAPHRAGM; HytrelR 2
402* 112181 PACKING, u-cup; nitrile 2
403* 188605 DIAPHRAGM; PTFE 2
* These parts are included in the Pump Repair Kit, which
may be purchased separately. See the Repair Kit
Matrix in instruction manual 308479 to determine the
correct kit for your pump.
{ These parts are included in Air Valve Repair Kit 236273,
which may be purchased separately.
F Supplied with Model 240623 only.
Y Replacement Danger and Warning labels, tags, and
cards are available at no cost.
HytrelR is a registered trademark of the DuPont Company.
SantopreneR is a registered trademark of the Monsanto Co.
