Parts
309577T 21
Ref. Part Description
Qty.
246830 246831 262647 246832 24Y175
1 240518 ROD, displacement; sst 1
240517 ROD, displacement; sst 11
246689 ROD, displacement; sst 1
15H110 ROD, displacement; sst 1
2 243346 CYLINDER, pump 1
243347 CYLINDER, pump 11
245413 CYLINDER, pump 1
17F955 CYLINDER, pump 1
3* 108526 O-RING; PTFE 2 2
107098 O-RING; PTFE
22
108822 O-RING; PTFE 2
4 248209 SLEEVE, cylinder; sst 1
248210 SLEEVE, cylinder; sst 11
248979 SLEEVE, cylinder; sst 1
15H112 SLEEVE, cylinder; sst 1
5 195892 HOUSING, valve, intake 1 1
195894 HOUSING, valve, intake 11
198219 HOUSING, valve, intake 1
7 239932 VALVE, piston 1
24U993 KIT, valve, piston 11
240580 VALVE, piston 1
24V125 VALVE, piston 1
8*‡ 249770 SPRING, intake ball 1
257842 SPRING, intake 1
9 239922 SEAT, intake; carbide; includes items 10 and 11 1 1
244199 SEAT, intake; carbide; includes items 10 and 11 11
240918 SEAT, intake; carbide; includes items 10 and 11 1
10* 107079 O-RING; PTFE 1 1
108526 O-RING; PTFE 11
107098 O-RING; PTFE 1
11* 105445 BALL, intake; sst; 0.5 in. (13 mm) 1 1
102972 BALL, intake; sst; 0.875 in. (22 mm) 11
107167 BALL, intake; sst; 1 in. (25 mm) 1
12 192624 GUIDE, ball 1 1
193027 GUIDE, ball 11
193391 GUIDE, ball 1
13* 117450 SEAL, u-cup, piston; UHMWPE 1 1
117449 SEAL, u-cup, piston; UHMWPE 11
117448 SEAL, u-cup, piston; UHMWPE 1
14* 15B078 BUSHING, piston 1
15J197 BEARING, lower 11
15B079 BUSHING, piston 1
17F958 BEARING, lower 1
15* 156593 O-RING; BUNA-N 1 1
156633 O-RING; BUNA-N 11
160325 O-RING; BUNA-N 1
