Motor/Air
Compressor
Cylinder Valve
Coil
15D560
N/O
Main
Pow
er Switch
117693
N/C Pr
imer Switch 119064
Open in
Prime
Mode
The Switch will remain closed
until
air flow is present. The
Gun being triggered or a Air
Leak
will cause the ball to lift up
and
open the circuit.
Main
Valve Coil
287326
N/C Air Flow
Sensor Switch
287326
15D559
Valve
asse
mbly
RTX
1500 Electrical and Air Ladder Diagram
Power
cord plugged in and Power Switch Off
.
120V
Load Blk Neutral Wht
M
Grnd
Air Flow
Air Flow
Air
Co
mpressor
Sensor Switch
Coil
45psi
Exhausted
Air
Air Cooler
Exhausted
Air
Air
Regu
lator
Air
Coil
Cylinder V
alve 15D560:With
Coil Vo
ltage Applied. This will allow air
to be exhausted and the weight of the
motor to
push the cylinder rod in and
remove tension on the Roto Flex Hose.
15D559
Valve
assembly
Cylinder Valve
Gun Valve
KEY
Air Flow
Electrical Switching Circuit
Exhausted
Air
To Next Page
