Daily Gun Care, Flushing, and Cleaning
3A0149C 17
Rotate the SwitchTip.
Disengage the trigger lock.
Trigger the gun into a pail to clear the clog.
Engage the trigger lock.
Return the SwitchTip to its original position.
Disengage the trigger lock and continue spraying.
F
IG. 28
F
IG. 29
Do not point gun at anyone or at any part of the body.
F
IG. 30
TI7200A
DISENGAGED
TI6580A
TI7202A
FIG. 31
F
IG. 32
F
IG. 33
TI6581A
ENGAGED
TI7201A
TI6582A
DISENGAGED
