Clutch Housing
3A0243A 19
Clutch Housing
Removal
1. Remove four screws (20) and lock washers (21)
which hold clutch housing (19) to engine.
2. Remove screw (35) from under mounting plate (D).
3. Pull off clutch housing (19).
Installation
1. Push on clutch housing (19).
2. Install four capscrews (20) and lock washers (21)
and secure clutch housing (19) to engine. Torque to
200 in-lb (22.6 N·m).
3. Install screw (35) from beneath mounting plate (D).
Torque to 26 ft-lb (35.2 N·m).
20
21
19
18
35
D
ti5486a
