Graco Bulldog - List of Models; Symbols

2 306839
List of Models
Part No. Series Pump Model
Displacement
Pump Model Ratio
Maximum
Fluid
Working
Pressure
Maximum
Pump
Air Input
Pressure
Maximum
Package
Air Input
Pressure
231047 B Bulldogr 217564 25:1 172 bar,
17 MPa
(2500 psi)
7 bar,
0.7 MPa
(100 psi)
10 bar,
1.0 MPa
(150 psi)
222529 B Severe-Duty
Bulldogr
222528 25:1 172 bar,
17 MPa
(2500 psi)
7 bar,
0.7 MPa
(100 psi)
10 bar,
1.0 MPa
(150 psi)
223987 B Quiet
Severe-Duty
Bulldogr
223986 25:1 172 bar,
17 MPa
(2500 psi)
7 bar,
0.7 MPa
(100 psi)
10 bar,
1.0 MPa
(150 psi)
Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
WARNING
INSTRUCTIONS
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury.
D This equipment is for professional use only.
D Read all instruction manuals, tags, and labels before operating the equipment.
D Use the equipment only for its intended purpose. If you are uncertain about usage, call your Graco
distributor.
D Do not alter or modify this equipment. Use only genuine Graco parts and accessories.
D Check equipment daily. Repair or replace worn or damaged parts immediately.
D Do not exceed the maximum working pressure stated on the equipment or in the Technical Data
for your equipment. Do not exceed the maximum working pressure of the lowest rated component
in your system.
D Use fluids and solvents which are compatible with the equipment wetted parts. Refer to the Tech-
nical Data section of all equipment manuals. Read the fluid and solvent manufacturer’s warnings.
D Route hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not expose
Graco hoses to temperatures above 82_C (180_F) or below –40_C (–40_F).
D Wear hearing protection when operating this equipment.
D Comply with all applicable local, state, and national fire, electrical, and safety regulations.
