DataTrak Operation
6 3A7634A
Codes
If the LED (AD in FIG. 1) is flashing, a symbol and code
will appear on the display. See Table 1.
To acknowledge the diagnosis and return to the normal
operating screen, press once to wake up the dis-
play, and once more to clear the code screen.
Replace DataTrak Battery
Table 1: Codes
Symbol Code Code Name Diagnosis Cause
Over-speed Agitator running faster
than set over-speed
limit.
Low material level.
Air pressure increased.
E-3 Low Battery Battery voltage is low. Low battery. Replace bat-
tery; see page 6.
FIRE AND EXPLOSION HAZARD
To reduce the risk of fire and explosion,
the battery must be replaced in a
non-hazardous location.
Use only an approved replacement battery
(see Table 2). Use of an unapproved
battery will void Graco’s warranty and
Intertek and Ex approvals.
Table 2. Approved Batteries
Energizer
®
alkaline # 522
Varta
®
alkaline # 4922
Ultralife
®
lithium # U9VL
Duracell
®
alkaline # MN1604
NOTE: All registered trademarks are the property of their
respective owners.
FIG. 2. DataTrak Battery Location
