Parts
3A7634A 7
Parts
Replacement safety labels, signs, tags, and cards
are available at no cost.
----- Not sold separately.
F
IG. 3
Ref. Part No. Description Qty
1 24B563 DATATRAK module 1
2 24A032 SWITCH, reed assembly 1
3 17S511 BRACKET, motor sensor 1
4 ----- SCREW, machine phillips panhead;
#6-32 UNC
1
5 ----- NUT, hex; #6-32 UNC 1
6 19Y733 BRACKET, motor sensor 1
7 15V262 LABEL, safety (not shown; located
on the bottom of the DataTrack
module (ref. 1))
1
