DISPLACEMENT PUMP P ARTS DRA WING & LIST
Ref
No. Part
No. Description Qty
201 180–656 PLUG 1
203 105–444*
BALL, sst, 0.3125” dia. 1
204 105–445* BALL,
sst, 0.5” dia. 1
205 105–522* SEAL,
u–cup, polyurethane 1
206 176–761* GASKET,
brass 1
207 176–759* PIN,
ball stop 1
208 176–749* V–PACKING,
leather 2
209 176–755* V–PACKING,
leather 2
211 176–754* GLAND,
male, Delrin  1
212 176–757* GLAND,
female, Delrin  1
213 176–750* GLAND,
male, Delrin  1
214 176–751 NUT,
hex, 1/2–20, sst 1
215 176–760 GUIDE,
ball, sst 1
216 177–929 CYLINDER,
alloy steel 1
217 176–882* V–PACKING,
polyethylene 3
218 176–997* V–P
ACKING, polyethylene 3
219 180–161* W
ASHER, backup, aluminum 1
220 180–073* GLAND,
female, plated steel 1
221 176–758 NUT,
packing/wet–cup 1
222 215–455 VAL
VE, intake 1
223 181–879 ROD,
piston, alloy steel 1
224 218–197 VALVE,
piston 1
*Also included in Repair Kit 222–587, sold separately .
Keep a kit on hand to reduce down time.
Model 218–215, Series C
Carbon Steel Displacement Pump
Includes items 201 to 224
NOTE: See the repair instructions for
important torque values and
procedures
203*
214
213*
217*
220*
205*
219*
224
215
204*
206*
222
223
218*
*209
*211
216
*212
221
201
0699!
207*
*208
