Graco MARK V

15309277
Service
Fig 24
223
203
218
V-Max UHWMPE, blue
208
217
213
214
204
221
224
205
219
215
212
227
222
202
221
216
206
210
Leather
Leather
201
Cross Sectional Reference
220
228
207
V-Max UHWMPE, blue
Pump 245889
Pump 244197
1
1
3
2
(203 on 244954, 246257, 245889, 287946)2
(223 on 244954, 246257, 245889)3
See Parts
112589, 189587
Pump 245889, 287946
See Parts
15D158, 118600
7683C
V-Max UHWMPE,
brown on
287814 & 287815
(227 on top of 212 244957)
(209 on 287946)
Technical Data
Maximum working pressure
All except 244957 3600 psi (250 bar, 24.8 MPa). . . . . . . . . . . . . . . . .
244957 4000 psi (276 bar, 27.6 MPa). . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid inlet size
244224, 244197, 245902 3/4 npt(m). . . . . . . . . . . . . . . . . . . . . . . . . . .
244201, 244954, 244409, 246257, 245889, 287946, 245904,
248736, 248971, 287814, 287815 1 npsm(m). . . . . . . . . . . . . . . . . . .
244957 1-1/4 npt(m). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid outlet size
244197 1/4 npt(f)244224, 244201, 244409, . . . . . . . . . . . . . . . . . . . . .
244954, 246257,245902, 245904, 248971
248736, 287814, 287815 3/8 npt(f). . . . . . . . . . . . . . . . . . . . . . . . . . . .
244957, 245889, 287946 (manifold) 1/2 npt(f). . . . . . . . . . . . . . . . . . .
Wetted parts stainless steel, PTFE,. . . . . . . . . . . . . . . . . . . . . . . . . . .
leather, nylon, zinc-plated carbon steel, tungsten carbide, chrome
plating, Delrin, polyethylene
NOTE: Delrin Loc-
tite is a registered trademark of the Loctite Company.
