3A0732U

EN

Instructions/Parts

Merkur

®

ES Spray

Packages

For low-volume fine finish spray applications. For professional use only.

15:1 Spray Packages

30:1 Spray Packages

100 psi (0.7 MPa, 7.0 bar) Maximum Air Inlet Pressure

See page 3 for model information, including maximum fluid

working pressure.

Important Safety Instructions

Read all warnings and instructions in

this manual. Save these instructions.

ti15590a

ti15589a

II 2 G Ex h T5 Gb X

Table of Contents

Other manuals for Graco Merkur ES

Instruction & Parts Manual42 pages

Questions and Answers:

V
Valerie MooreAug 21, 2025
What to do if my Graco Paint Sprayer pump fails to operate?
- W
  Wendy HollandAug 21, 2025
  If the Graco Paint Sprayer pump fails to operate, first check for any restrictions in the line, ensure an adequate air supply, and verify that all valves are open. If those are not the cause, inspect the fluid hose and gun for obstructions, and make sure the fluid hose ID is appropriately sized. Another potential cause could be fluid dried on the displacement rod (119). If so, clean it and keep the packing nut wet-cup filled with Graco throat seal liquid (TSL).
K
kimberlyriveraAug 22, 2025
What to do if my Graco Paint Sprayer pump operates but does not prime?
- J
  Joseph LawrenceAug 23, 2025
  If your Graco Paint Sprayer pump operates but does not prime, it might be due to held open or worn ball check valves or piston packings. Try to clear the valve and replace the packings. Also, check the suction hose o-ring (38); if it's worn, replace it.
V
Veronica WestAug 25, 2025
How to prevent icing inside the motor of my Graco Merkur ES Paint Sprayer?
- J
  Julie SaundersAug 25, 2025
  If you're experiencing icing inside the motor of your Graco Paint Sprayer, it's likely because the air motor is operating at high pressure or a high cycle rate. To resolve this, reduce the pressure, cycle rate, or duty cycle of the motor. Also, reduce the dew point of compressed air in the moisture coalescing filter.
M
Melissa FryAug 27, 2025
Why is the output low on both strokes of my Graco Merkur ES?
- A
  amcconnellAug 27, 2025
  If your Graco Paint Sprayer pump operates but the output is low on both strokes, start by checking for any restrictions in the line, ensuring an adequate air supply, and verifying that the valves are open and not clogged. Additionally, inspect the fluid hose and gun for any obstructions, and make sure the fluid hose ID is not too small; clear any obstructions or use a hose with a larger ID. Finally, worn packings in the displacement pump can also cause low output; in this case, replace the packings.
C
Christopher ChangAug 28, 2025
What causes low output on downstroke of Graco Paint Sprayer?
- K
  Kenneth LopezAug 28, 2025
  If your Graco Paint Sprayer pump operates, but the output is low on the downstroke, it could be caused by ball check valves or piston packings being held open or worn. Clear the valve, and replace the packings.
N
nbellAug 29, 2025
Why is the output low on both strokes of my Graco Merkur ES pump?
- T
  Thomas HernandezAug 29, 2025
  If your Graco Paint Sprayer pump operates but the output is low on both strokes, the issue could stem from a restricted line, inadequate air supply, or closed/clogged valves. Ensure the line is clear, increase the air supply, and check that the valves are open. Another possibility is an obstructed fluid hose or gun, or a fluid hose with an ID that's too small. Make sure they are clear and consider using a hose with a larger ID. Finally, worn packings in the displacement pump can also cause this issue; if so, replace the packings.
P
paul90Aug 31, 2025
Why is fluid being pumped visible in the packing nut wet-cup of my Graco Merkur ES?
- D
  Debra WilliamsAug 31, 2025
  If you notice fluid being pumped is visible in the packing nut wet-cup of your Graco Paint Sprayer, this is likely due to worn throat packings. Try tightening the packing nut, and if that doesn't resolve the issue, replace the throat packings.
A
Audrey JonesSep 1, 2025
Why does my Graco Merkur ES Paint Sprayer have erratic pump speed?
- S
  Sarah ThomasSep 1, 2025
  If your Graco Paint Sprayer has an erratic or accelerated pump speed, it could be due to an exhausted fluid supply. Refill the fluid and prime the pump. Another cause could be held open or worn ball check valves or packings. In that case, clear the valve and replace the packings.
K
Kelsey PrattSep 3, 2025
Why is the output low on the downstroke of my Graco Paint Sprayer pump?
- K
  Kevin TorresSep 3, 2025
  If your Graco Paint Sprayer pump operates, but the output is low on the downstroke, it could be due to held open or worn ball check valves or piston packings. Clear the valve and replace the packings.
T
Thomas ClarkSep 5, 2025
What to do if the air motor of my Graco Merkur ES Paint Sprayer will not run?
- C
  Christopher MooreSep 5, 2025
  If the air motor of your Graco Paint Sprayer will not run, it could be due to a damaged air valve (214) or a damaged pilot valve (213). Consider replacing or servicing the air valve (214) or replacing the pilot valves (213).

Graco Merkur ES Specifications

General

Type	Airless
Max Pressure	3000 psi
Hose Length	50 ft
Maximum Working Pressure	3000 psi
Pump Type	Piston
Voltage	120V
Nozzle Size	0.015-0.021 inches
Horsepower	N/A (Air-powered)
Amperage	N/A (Air-powered)
Tip Size Range	0.009 to 0.021 inches
Applications	Wood Finishing
Fluid Compatibility	Wide range of fluids, including paints, stains, lacquers, and coatings. Check specific model for compatibility.
