332245G

EN

Instructions-Parts

Merkur

®

High Pressure Sprayer

For protective coating applications in hazardous or non-hazardous locations. For

professional use only.

See page 2 for model information, including maximum

working pressures.

Important Safety Instructions

Read all warnings and instructions in this

manual. Save these instructions.

ti21103a

ll2GExhT3Gb

Repair Kits

Accessory Kits

See page 25

Table of Contents

Questions and Answers:

R
Robert JonesJul 27, 2025
How to fix a Graco Merkur when the pump fails to operate?
- R
  Ruben GuerreroJul 28, 2025
  If the Graco Paint Sprayer pump fails to operate, first check for a restricted line or inadequate air supply and ensure the valves are open. Clear any obstructions and increase the air supply. If the issue continues, inspect the fluid hose and gun for any blockages, clearing them if necessary, and ensure that the fluid hose ID is adequate. Also, check the displacement rod for dried fluid, cleaning it and keeping the wet-cup filled with Graco throat seal liquid (TSL).
J
Judy PattersonAug 3, 2025
Why is my Graco Paint Sprayer pump speed erratic?
- D
  destinyaustinAug 3, 2025
  If the Graco Paint Sprayer pump operates erratically or at an accelerated speed, first refill the fluid supply and prime the pump. If the issue persists, the ball check valves or packings may be held open or worn. In this case, clear the valve and replace the packings.
T
Tiffany FosterAug 8, 2025
What to do if Graco Paint Sprayer output is low on both strokes?
- L
  Luis BowenAug 8, 2025
  If the Graco Paint Sprayer pump operates but the output is low on both strokes, check for a restricted line or inadequate air supply, and ensure that all valves are open and not clogged. Clear any obstructions and increase the air supply. Also, inspect the fluid hose and gun for obstructions, clearing them as necessary. If the fluid hose ID is too small, replace it with a hose having a larger ID.
H
hensleybrianAug 14, 2025
What to do if Graco Paint Sprayer output is low on downstroke?
- H
  Howard RodriguezAug 15, 2025
  If the Graco Paint Sprayer pump operates, but the output is low on the downstroke, the ball check valves or piston packings may be held open or worn. Clear the valve and replace the packings.
