Installation
6 332245G
Installation
Key:
A Air Shutoff Valve (optional accessory)
B Air Filter (optional accessory)
C Bleed Type Master Air Valve
D Pump Air Pressure Gauge
E Pump Air Pressure Regulator
F Cart
G Fluid Drain Valve
H Spray Gun
J Gun Fluid Supply Hose
K Whip Hose
L Pump Fluid Outlet
M Grounding Wire
N Wet-Cup
P Pump Fluid Inlet
R Suction Hose
FIG. 1: Typical Installation
D
P
L
C
M
K
E
R
J
H
F
N
ti21104a
G
B
A
