Graco Merkur series User Manual

Parts
22 332245G
Pump System Parts
101
102
110
ti21119a
Torque to 50-55 ft-lb (68-75 N•m).
1
Torque to 50-60 ft-lb (68-81 N•m).
2
Torque to 75-80 ft-lb (102-108 N•m).
3
Assemble pump (102) to top of within +/-
one thread. Torque jam nut of pump to
70-75 ft-lb (95-102 N•m).
4
105
104
103
106
107
108
109
1
2
3
4
