Graco Merkur series User Manual

Models
332245G 3
Models
Merkur X48 Package
Merkur X72 Package
Bare Package
Bare packages do not include a gun or hose.
Maximum Recommended Tip Size
Part
Gun Hoses Accessories
Maximum
Inlet Air
Pressure
psi (MPa, bar)
Maximum
Fluid Working
Pressure
psi (MPa, bar)
Maximum
Fluid Flow
Rate
gpm (lpm)
Gun Tip Size
Gun
Fluid
Hose
Gun
Fluid
Whip
Hose
Suction
Tube
Fluid
Filter
Drain
Valve
Kit
16U920 XTR504 0.019
✔ ✔ ✔ ✔
100 4800 (33, 330) 1.2 (4.5)
Part
Gun Hoses Accessories
Maximum
Inlet Air
Pressure
psi (MPa, bar)
Maximum
Fluid Working
Pressure
psi (MPa, bar)
Maximum
Fluid Flow
Rate
gpm (lpm)
Gun Tip Size
Gun
Fluid
Hose
Gun
Fluid
Whip
Hose
Suction
Tube
Fluid
Filter
Drain
Valve
Kit
16U918 XTR704 0.019
✔ ✔ ✔ ✔
100 7200 (50, 500) 0.8 (3)
Part
Description
Maximum
Inlet Air
Pressure
psi (MPa, bar)
Maximum
Fluid Working
Pressure
psi (MPa, bar)
Maximum
Fluid Flow
Rate
gpm (lpm)
16V174 Merkur X72 100 7200 (50, 500) 0.8 (3)
16V175 Merkur X48 100 4800 (33, 330) 1.2 (4.5)
Model Tip Size
Merkur X72 0.021
Merkur X48
0.025

Graco Merkur series Specifications

General

Brand	Graco
Model	Merkur series
Category	Paint Sprayer
Language	English
