O4658
04720
01069A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1a
1b
1c
1d
1e
1f
L
L
L
L
L
18
19
20
21
22
23
24
82Z–228
Rev A
Supplement to instruction manual 820–228
Nova
R
spx
INJECTION
HAZARD
This form is only a quick reference to the
features and frequently ordered parts of
this sprayer
. T
o reduce the risk of seri
-
ous injury
, including fluid injection, while operating
or repairing this sprayer
, follow the warnings and
instructions in manual 820–228.
INSTRUCTIONS
WARNING
Model 820–226, Series A
Ref
No. Part No. Description
1 820–887
Displacement Pump
1a 820–287
. Packing Nut
1b 820–970
. Manifold
1c 820–973
. Cylinder
1d 820–971
. Displacement Rod
1e 820–974
. Piston V
alve
1f 820–975
. Inlet V
alve
2 820–882
Drive Housing Kit
3 820–604
Connecting Rod
4 820–894 Pressure Transducer
5 820–923
Pressure Control Kit
6 821–053
Suction Hose & T
ube
7 821–054
Drain T
ube
8 821–060 Clip
9 821–058 Strainer
10 187–791
Danger Label
11 821–051 Handle
12 820–880
Motor Kit
13 820–605 Gear Reducer
14 820–884 Crankshaft
15 821–056 Leg
16 820–912
Drain V
alve Handle
17 820–911 Pin
18 820–910 V
alve Base
19 820–904
Drain V
alve Kit
20 820–914
Motor Start Board
21 820–342 ON/OFF Switch
22 820–341 Boot
23 821–005
Drain Elbow
24 820–924 Gasket
Y
Extra danger labels are available for free.
Packing Repair Kit
820–908
Includes all parts marked with a
L
Motor Brush and Spring Kit 821–022
Motor Brush Spring Clip 821–061
