820-228 5
06197
Major Components
C
Fig.
1
G
E
F
D
A
K
M
B
H
N
J
L
05963
A Motor
DC motor
, 120 V
ac, 15A, 1 phase
B
Drive Assembly
T
ransfers power from DC motor to the displacement pump
C
Pressure Adjusting Knob
Controls fluid outlet pressure
D
ON/OFF Switch
Power switch that controls 120 V
ac power to sprayer
E
Fluid Outlet
Hose and spray gun is connected here
F
Displacement Pump
Pressurizes fluid to be sprayed through spray gun
G
50 ft (15 m) Main Hose
1/4 in. ID, grounded, nylon hose with spring guards on both ends
H
RAC IV T
ip Guard
Reverse-A-Clean (RAC) ti
p g
uard reduce
s t
he ris
k o
f f
lui
d i
njectio
n i
njury
J
FTx Gun
High pressure spray gun with gun safety latch
K
RAC IV Switch T
ip
RAC switch tip atomizes fluid and removes clogs from spray tip without
removing tip from spray gun
L
Pressure Drain V
alve
Relieves fluid pressure when open
M
Pressure Control
Controls motor to maintain fluid pressure. W
orks with pressure
adjusting knob.
N
Spray Gun Safety Latch
Inhibits accidental triggering of spray gun
