Mounting Dimensions
309474U 21
Mounting Dimensions
Part Thread Dimension A
233757
234263
17L324
M5 24 mm (0.95 in.)
233758
234262
M5 24 mm (0.95 in.)
233759
234267
M5 24 mm (0.95 in.)
233773
234272
M5 24 mm (0.95 in.)
233774
234273
M5 24 mm (0.95 in.)
233809
234256
M5 24 mm (0.95 in.)
233810
234257
M5 24 mm (0.95 in.)
233811
234255
M5 36 mm (1.42 in.)
233812
234258
M5 24 mm (0.95 in.)
233950
234261
M5 24 mm (0.95 in.)
A
