Graco P20-VM - List of Models

List of Models
309474U 3
List of Models
 17L324 is designed for water-based systems.
Key to Model Designation
Fluid Pressure Regulators
Part Series Model Type Maximum Fluid Inlet Pressure Regulated Pressure Range
233757
234263
B
B
P20-VM
P20-VM npt
Mechanical,
fluid pressure
580 psi (4000 kPa, 40 bar) 15-290 psi
(100-2000 kPa, 1-20 bar)
17L324 A P20-VM npt Mechanical,
fluid pressure
1500 psi (10.3 MPa, 103 bar) 15-290 psi (100-2000 kPa,
1-20 bar). Preset to 185 psi
(1275 kPa, 13 bar).
233759
234267
B
B
P50-VM
P50-VM npt
Mechanical,
fluid pressure
1015 psi (7000 kPa, 70 bar) 145-725 psi
(1000-5000 kPa, 10-50 bar)
233773
234272
B
B
P10-VP
P10-VP npt
Pneumatic,
fluid pressure
580 psi (4000 kPa, 40 bar) 6-145 psi
(40-1000 kPa, 0.4-10 bar)
233774
234273
B
B
P10-VM
P10-VM npt
Mechanical,
fluid pressure
580 psi (4000 kPa, 40 bar) 15-145 psi
(100-1000 kPa, 1-10 bar)
233809
234256
B
B
P10-VP, OEM
P10-VP, OEM npt
Pneumatic,
fluid pressure
580 psi (4000 kPa, 40 bar) 6-145 psi
40-1000 kPa, 0.4-10 bar)
Back Pressure Regulators
Part Series Model Type
Maximum Permanent Supply
Pressure
Regulated Pressure Range
233758
234262
B
B
P10-RM
P10-RM npt
Mechanical,
back pressure
145 psi (1000 kPa, 10 bar) 15-145 psi
(100-1000 kPa, 1-10 bar)
233810
234257
B
B
P10-RP
P10-RP npt
Pneumatic,
back pressure
145 psi (1000 kPa, 10 bar) 15-145 psi
(100-1000 kPa, 1-10 bar)
233811
234255
B
B
P20-RM DN13
P20-RM DN13 npt
Mechanical,
back pressure
290 psi (2000 kPa, 20 bar) 29-290 psi
(200-2000 kPa, 2-20 bar)
233812
234258
B
B
P50-RM
P50-RM npt
Mechanical,
back pressure
725 psi (5000 kPa, 50 bar) 73-725 psi
(500-5000 kPa, 5-50 bar)
233950
234261
B
B
P20-RM DN1
P20-RM DN1 npt
Mechanical,
back pressure
290 psi (2000 kPa, 20 bar) 15-290 psi
(100-2000 kPa, 1-20 bar)
Pressure regulation valve e.g. P20- R M DN13 npt
npt version
Valve Seat Orifice 13mm
Operating Mode P - pneumatic
M - mechanical
Action V - pressure regulation
R - back-pressure regulation
Regulation max 20 bar pressure
