Remote Loading
4 3A1244F
Systems With A Display Module,
262384, 24F493
1. The following screen will be shown when the display
turns on.
2. Select which software is applied to each module
when multiple software options exist. The following
screen is not present in all systems. See system
specific manual for more details. Press to
continue.
3. Wait for update to complete.
NOTE: The approximate time until completion is shown
along bottom of progress bar.
4. Updates are complete. Icon indicates update
success or failure. See Icon Table. Press to
continue.
Communications with other modules established.
Key:
A Module Serial Number
B Software currently on module
C Software available for module
A
BC
Icon Description
Update successful
Update unsuccessful
Update complete; no change necessary.
Modules were updated or didn’t require an
update; however, one or more modules
need to be updated manually with a token.
To Next Page
