See section 4-B for instructions on how to remove back
support.
On the rear of the seat, detach 2 lower seat pad elastic
straps from hooks as shown.
Remove seat cover as shown.
WARNING! Inspect and clean buckle from
time to time to remove any objects or
debris that could prevent latching.
From bottom of car seat, rotate metal retainer to side in
order to push it through slot easier. Pull buckle strap from
child restraint as shown.
To clean buckle, place in a cup of warm water and gently
agitate the buckle. Press the red button several times while
in the water.
DO NOT SUBMERGE THE BUCKLE STRAP. DO NOT USE
SOAPS, HOUSEHOLD DETERGENTS or LUBRICANTS.
Shake out excess water and allow to air dry. Repeat steps
as needed until it fastens with a click. Re-insert the buckle
into the same slot it was removed. Pull up on buckle strap to
make sure it is secured.
8-B Cleaning Buckle Strap
