Graef UNA 9 - Set Up and Function Overview

Universal Slicer Master UNA 9
20
EN
Set up and function
Total overview
Technical data
Dimensions (L x W x H) 470 x 280 x 300 mm
Weight approx. 4.5 kg
Cutting width 0 - 15 mm
Cutting height 132 mm
Cutting length 220 mm
Operating voltage 230 volt
output 45 watt
Peak cutting output up to 170 watt
1) Blade cover plate
2) Cutting blade
3) Geometrical manual
wheel for setting the
cutting width
4) Support feet
5) Pulse switch
6) Permanent switch
7) scrap container
8) Skid
1
4
3
2
4
5
6
8
7
