Model 1000 1200
Electrical data P1 Rated absorbed power [W] 900 1100
P2 [W] 650 750
Mains voltage [V] 1 ~ 230 AC 1 ~ 230 AC
Mains frequency [Hz] 50 50
Current [A] 3.8 4.8
Capacitor [µF] 12.5 12.5
Capacitor [Vc] 450 450
Hydraulic data Max. flow rate [l/min] 95 95
Max. head [m] 36 46
Max. head [bar] 3.6 4.6
Max. immersion depth [m] 12 12
Min. submersion height [cm] 12 12
Cut in pressure [bar] 2.6+- 0.2 2.6+- 0.2
Range of use Length of power cable [m] 15 15
Type of cable H07 RNF H07 RNF
Grade of motor protection IP 68 IP 68
Insulation class B B
Liquid temperature range [°C]
according to EN 60335-2-41 for domestic use
0 °C / +35 °C 0 °C / +35 °C
Max. particle dimension [mm] Ø 1 Ø 1
Max. ambient temperature [°C] +40 °C +40 °C
Weight DNM GAS 1'' F 1'' F
Net/Gross weight approx. [kg] 10 / 12 10 / 12
Table 3
The pump which does not stand on a base cannot support the weight of the pipes, which must be
supported in some other way.
4. MANAGEMENT
4.1 Storage
All the pumps must be stored in a dry covered place, with possible constant air humidity, free from vibrations and dust.
They are supplied in their original pack in which they must remain until the time of installation.
4.2
Transport
Avoid subjecting the products to needless impacts and collisions.
4.3 Weight and dimensions
The adhesive plate on the packaging indicates the total weight of the pump and its dimensions.
5. WARNINGS
The pumps must never be carried, lifted or allowed to operate suspended from the power cable; use
the handle and cord provided.
The pump must never be allowed to run when dry.
The sealing device contains lubricant which is non-toxic but which may alter the characteristics of the water, in the
case of pure water, if the pump were to have any leaks.
6. INSTALLATION
Screw on the nipple with coupling supplied in the packaging, which is suitable for pipes with dimensions ¾’’ and 1’’; if you
want to use a pipe with a larger diameter, change the coupling. Use a pipe tightening clamp to secure the pipe to the
fitting Fig.1
It is advisable to use pipes having a minimum internal diameter of ¾’’ mm, to avoid the decrease of pump
performance.
To avoid obstruction of the suction passages, it is recommended to check periodically that no dirt has accumulated in
the collection trap (leaves, sand, etc.). It is advisable to leave a minimum distance of 20 cm to avoid clogging of the
suction grid (Fig.2)
Insert the plug in a socket, main power must to be 230V.
the pump must be activated only if immersed in water. Consider a minimum submersion of 12 cm. If the water is
finished the pump must be stopped immediately, taking the plug out of the socket.
The pump must be placed in a stable position inside a trap or in the lowest part of the place where it is installed.
Ensure that the minimum dimensions of the trap in which it is housed are as follows:
