20
SECTION V
PARTS LIST
NOTE: Call the factory service department (630-653-3377) for those parts not listed. Due to revisions and
improvements it is suggested that you confirm the part number with the factory service department before placing
an order.
PART NUMBER / DESCRIPTION
48200 Standard cradle, 25” long
48220 Four-sided cradle
48222 Oversize cradle, 32” long
48205 Mounting post (for cradle)
40477 10-32 x 1” set screw
030075 Enclosure base
48110 Enclosure cover
48106 Side handle
48118 Ferrule (for side handle)
48122 Handle shim, U-channel
48112 ¼-20 x ½” button head screw
48107 Rear handle
48137 Spacer 2” x ½” diameter
48138 ¼-20 x 3” flat head screw
341003 Universal Power Supply (12 volt)
600059 Power supply mounting bracket
40517 Power cord
66011 Rubber foot with washer
20108 10-32 x ½” button head screw
48502 Load cell transducer DEBB-100
48511 10-32 x 1-1/2” socket head cap
screw
48503 Loading arm
48508 ¼-20 x ½” socket head cap screw
48504 Loading block
50511 5/16” x 5/8” shoulder bolt
PART NUMBER / DESCRIPTION
HS-202 DURACELL “D” battery
630225 Battery holder and harness
700050 Instrument board assembly
450012 Microcomputer with software, V
X.XX.4
EU1022 7135 A/D converter IC
350038 LTC1100 instrument amp IC
EU1025 LTC 1050 operational amp IC
700048 Display board assembly
EDS1005 HDSP-E101 LED 7 segment digit,
0.43”, red
ELD1033 HLCP-H100 0.35” x 0.75” LED light
bar, red
350002 SAA1064 display driver IC
350003 PCF8754 I/O expander IC
48217 Scales liners, carton of 500
48800-1 Mobile weighing cart for 4802
48859 Scale liner dispenser shelf for mobile
weighing cart
530181 Operating instruction label
070060 Operating and Service Manual
720022 Front panel with membrane switch
(LB and KG version)
720023 Front panel with membrane switch
(Kilogram only version)
720005 Front panel with membrane switch
for serial numbers below 20000
