765041982 Rev. 000 26
Servicemenu
Service
To enter the service menu, push +
simultaneously for about 6 seconds.
The first menu option "A" (Alarm settings) is displayed at the secondary display. Menu
options "A", "P", "C", "F", "D", "Ter" each have a submenu, options "P-A" …. "P-E" show the
temperature of each sensor at the primary display.
The keys and are used to navigate through the menus, with the actual menu
option is selected. With and the settings are changed, navigation in submenus
respectively . Changes are saved by pushing (A beep sounds for confirmation). Push
to exit the menu/menu option.
Alarm settings
"Presentation", Display reading
"Compressor", Control parameters for compressor
"Fan", Control parameters for evaporator fan
"Defrost", Defrost parameters
"Test Relay" Manual test of relays
"Probe - A" Room sensor temperature display (Conn. A)
…
… B (evaporator sensor), C, D respectively (condenser sensor)
"Probe - E" Extra sensor temperature display (Conn. E)
