GRP260x Administration Guide
Version 1.0.3.42
Allow DHCP Option
43 and Option 66
Override Server
DHCP option 66 originally was only designed for TFTP server. Later, it was
extended to support an HTTP URL. GRP phones support both TFTP and
HTTP server via option 66. Users can also use DHCP option 43 vendor
specific option to do this. DHCP option 43 approach has priorities. The phone
is allowed to fall back to the original server path configured in case the server
from option 66 fails. The default setting is “Yes”.
Allow DHCP Option
120 to override SIP
Server
Enables DHCP Option 120 from local server to override the SIP Server on
the phone. The default setting is “No”
Additional Override
DHCP Option
When enabled, users could select Option 150 or Option 160 to override the
Firmware server instead of using the configured firmware server path or the
server from option 43 and option 66 in the local network. Please note this
option will be effective only when option “Allow DHCP Option 43 and Option
66 to Override Server” is enabled. The default setting is “None”.
Download and
Process ALL Available
Config Files
By default, device will provision the first available config in the order of
cfgMAC, cfgMAC.xml, cfgMODEL.xml, cfg.xml and devMAC.cfg
(corresponding to device specific, model specific, and global configs). If set
to Yes, device will download and apply (overwrite) all available configs in the
same order.
When user protection is on, pvalues that user sets will not be changed by
provision or provider.
Phone will multicast SUBSCRIBE for provision if this feature is enabled.
Validate Hostname in
Certificate
To validate the hostname in the SSL certificate
Enable SIP Notify
Authentication
Device will challenge NOTIFY with 401 when set to Yes
Press Start to begin Factory Reset of the phone.
Maintenance → System Diagnosis
If set to SSL/TLS, the syslog messages will be sent through secured TLS
protocol to syslog server.
To Next Page
