Page | 36

GRP261X /GRP2624/GRP2634 User Guide

Version 1.0.5.48

Figure 9: GRP2615 Keyboard

Figure 10: GRP2616 Keyboard

Table 9: GRP261X/GRP2624/GRP2634 Keypad Buttons

Contacts. Press to view and edit contact information.

Hold. Press to put call on hold or resume the call.

Mute. Press to mute or unmute the call.
