P a g e | 20
GXP16XX User Guide
Version 1.0.7.18
Dimension: 220.5mm (L) x 192.5mm (W) x 76.0mm (H) (with handset)
Unit weight: 0.8kg; Package weight: 1.2kg
GXP1628 phone, handset with cord, base stand, universal power supply,
network cable, Quick Installation Guide, brochure, GPL license, BLF label
cards
FCC : Part 15 (CFR 47) Class B
CE : EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1
RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS 60950.1
Table 4: GXP1630 Technical Specifications
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, HTTP/HTTPS,
FTP/FTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE,
SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS,
SRTP
Dual switched auto-sensing 10/100/1000 Mbps Ethernet ports, integrated
PoE
132 x 64 backlit graphical LCD display
3 line keys with dual-color LED and 3 SIP accounts. 3 XML programmable
context sensitive soft keys. 5 (navigation, menu) keys. 8 BLF keys. 13
dedicated function keys for PAGE/INTERCOM, PHONEBOOK, MESSAGE,
HOME, HOLD, RECORD, MUTE, HEADSET, TRANSFER, CONFERENCE,
SEND and REDIAL, SPEAKERPHONE, VOLUME
Support for G.711µ/a, G.722 (wide-band), G.723.1, G.726-32, G.729 A/B,
iLBC, in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO)
Hold, transfer, forward (unconditional/no-answer/busy), call park/pickup, 4-
ways conference, shared-call-appearance (SCA) / bridged-line-appearance
(BLA), downloadable phone book (XML, LDAP, up to 1000 items), call waiting,
call history (up to 200 records), off-hook auto dial, auto answer, click-to-dial,
flexible dial plan, Hot Desking, personalized music ringtones, server
redundancy & fail-over.
RJ9 headset jack (allowing EHS with Plantronics headsets)
Yes, HD handset and speakerphone with support for wideband audio
Yes, 2 angle positions available, Wall Mountable
