Grandstream Networks GXP1780 Quick Start Guide

5 6
Note: For the detailed user manual, please download from:
http://www.grandstream.com/support
Tips For Using the Keypad:
PHONE CONFIGURATION:
Congure the GXP178x using Web Browser:
1. To access the MENU, press the round MENU button.
2. Navigate the menu by using the UP/DOWN and LEFT/RIGHT buttons.
3. Press the round MENU button to conrm a menu selection.
4. The phone automatically exits MENU mode when there is an incoming call,
the phone goes off-hook or the MENU mode is left idle for 60 seconds.
1. Ensure your phone is powered up and connected to the Internet.
2. Press the UP button to see the IP address.
3. Type the phone’s IP address in your PC browser (See gure on right).
4. The default administrator username and password are “admin”; the default end-
user username is “user“ and the password is “123”.
Congure the GXP178x using the Keypad:
1. Make sure the phone is idle.
2. Press the MENU button to access the keypad MENU to congure the phone.
3. Select MENU-> Phone-> SIP-> Account to congure settings for SIP Proxy,
Outbound Proxy, SIP User ID, SIP Auth ID and SIP Password.
4. Follow MENU options to congure the basic features of the phone, for ex-
ample: the IP address if using a static IP. For details, please check GXP17xx User
Manual.
5. Please contact your ITSP (Internet Telephony Service Provider) for additional
settings that may be necessary to congure the phone.
Message Waiting
Indicator
Contacts
Transfer
Conference
Mute
Standard Keypad
Navigation keys
Line keys
Soft keys
Volume
Speaker
Headset
Menu/OK Key
Line keys
Send
This product is covered by one or more of the U.S. patents (and any foreign patent
counterparts thereto) identied at www.cmspatents.com.

Grandstream Networks GXP1780 Specifications

General

Brand	Grandstream Networks
Model	GXP1780
Category	IP Phone
Language	English
