Different Networks for
Data and VoIP Calls
Configures whether to set up different networks for the phone data and the call. If set to
“Yes”, you need to configure the data network and VoIP network respectively.
IPV4
IPv4 Address Type
Configures the appropriate network settings on the phone. Users could select from “DHCP”,
“Static IP” or “PPPoE”(Point-to-point Protocol over Ethernet).
By default, it is set to “DHCP”.
DHCP VLAN Override
Selects the DHCP Option VLAN mode. When set to “DHCP Option 132 and DHCP option
133”, the phone will get DHCP option 132 and 133 as VLAN ID and VLAN priority. When set
to “Encapsulated in DHCP Option 43”, the phone will get values from Option 43 which
encapsulate VLAN ID and VLAN priority.
Note: Please make sure the “Allow DHCP Option 43 and Option 66 to Override Server” setting
under maintenance
🡪
upgrade is checked. The default setting is ” Encapsulated in DHCP Option
43 “.
DHCP Host name (Option
12)
Sets the name of the client in the DHCP request. It is optional but may be required by some
Internet Service Providers.
Vendor Class ID
(Option 60)
Configures the vendor class ID header in the DHCP request.
The default setting is Grandstream GXV3480.
IP Address Defines the phone’s static IP address if the static IP is used.
Subnet Mask Determines the network’s subnet mask if the static IP is used.
Default Gateway Defines the network’s gateway address if the static IP is used.
DNS Server 1 Configures the primary DNS IP address if the static IP is used.
DNS Server 2 Configures the secondary DNS IP address if the static IP is used.
PPPoE Account ID Configures the PPPoE account ID if the PPPoE is used.
PPPoE Password Sets the PPPoE password if the PPPoE is used.
Layer 2 QoS
802.1Q/VLAN Tag
(Ethernet) for Data
Assigns the VLAN Tag of the Layer 2 QoS packets for Ethernet.
The Default value is 0
Note: When Different Networks for Data and VoIP Calls set to Yes, then this option will be
applied for Data.
Layer 2 QoS 802.1p
Priority Value (Ethernet)
for Data
Assigns the priority value of the Layer 2 QoS packets for Ethernet.
The Default value is 0.
Note: When Different Networks for Data and VoIP Calls set to Yes, then this option will be
applied for Data.
IPV6
IPv6 Address Type
Configures the appropriate network settings on the phone.
Users could select from “Auto-configured” or “Statically configured”.
Enable IPv6 Privacy
Address
Configures whether to enable IPv6 privacy address. If enabled, the device will carry multiple
IPv6 addresses. Note: This may cause problems with some servers such as BroadSoft and
result in account registration failure (invalid or no response).
Static IPv6 Address The static IPv6 address when static IPv6 is used.
IPv6 Static Gateway The static gateway when static IPv6 is used.
IPv6 Prefix Length
Enter the IPv6 prefix length in “Statically configured” IPv6 address type.
Default is 64.
DNS Server 1 The DNS Server 1 when static IP is used.
DNS Server 2 Configures the secondary DNS IP address.
