Grandstream Networks GXV34 Series Administration Guide

Automatic
Download Interval
Determines how the phone system to send the request to the server to download the phonebook
file. It can be selected from the dropdown list:
None
5 Minutes
30 Minute
1 Hour
2 Hour
4 Hour
6 Hour
8 Hour
12 Hour
Download Now Starts downloading the XML phonebook to the phone immediately.
Table 48: Applications/Contacts
Applications/LDAP Phonebook
Connection Mode
Selects which protocol will be used for LDAP searching, LDAP or LDAPS.
Default is “LDAP”.
Server Address Configures the URI of the LDAP (Lightweight Directory Access Protocol) server.
Port
Configures the LDAP server port.
The default LDAP port number is 389.
Base DN
Determines the LDAP search base. This is the location in the directory where the search is
requested to begin.
Example:dc=grandstream, dc=comou=Boston, dc=grandstream, dc=com
Username
Configures the bind “Username” for querying LDAP servers. Some LDAP servers allow
anonymous binds in which case the setting can be left blank.
Password
Specifies the bind “Password” for querying LDAP servers. The field can be left blank if the LDAP
server allows anonymous binds.
LDAP Name Attributes
Configures the “name” attributes of each record which are returned in the LDAP search result.
This field allows the users to configure multiple space separated name attributes.
Example:cn sn description
LDAP Number
Attributes
Configures the “number” attributes of each record which are returned in the LDAP search result.
This field allows the users to configure multiple space separated number attributes.
Example: telephoneNumber, telephoneNumber Mobile
LDAP Mail Attributes
Determines the “mail” attributes of each record which are returned in the LDAP search result.
Example: mail
