FIRMWARE VERSION 1.0.0.5 HT802 USER MANUAL Page 28 of 46
If set to Yes, config file is authenticated before acceptance. This protects the
configuration from an unauthorized change.
The user specify SSL certificate used for SIP over TLS in X.509 format.
The user specify SSL private key used for SIP over TLS in X.509 format.
SIP TLS Private Key
Password
User specify password to protect the private key above.
User specify the Auto Configuration Server’s URL (TR-069 protocol)
User specify the ACS Username
User specify the ACS password
Default is No. If set to YES, device will send inform packets to the ACS
Frequency that the inform packets will be sent out to the ACS
Connection Request
Username
Set a user name for the ACS to connect to this device
Connection Request
Password
Set a password for the ACS to connect to this device
The Cert File for the phone to connect to the ACS via SSL.
The Cert Key for the phone to connect to the ACS via SSL.
Configuration option is set ring cadence on all FXS ports for all incoming calls. (Syntax:
c=on1/off1-on2/off2-on3/off3(only 3 cadences maximum)) Default is set to c=2000/4000;
(US standards)
Using these settings, users can configure tone frequencies and cadence according to
their preference. By default they are set to North American frequencies. Configure these
settings with known values to avoid uncomfortable high pitch sounds. ON is the period of
ringing (“On time” in ‘ms’) while OFF is the period of silence. In order to set a continuous
tone, OFF should be zero. Otherwise it will ring ON ms and a pause of OFF ms and then
repeat the pattern.
Example configuration for N.A. Dialtone:
f1=350@-13,f2=440@-13,c=0/0;
Syntax: f1=freq@vol, f2=freq@vol, c=on1/off1-on2/off2-on3/off3; [...]
