FIRMWARE VERSION 1.0.0.5 HT802 USER MANUAL Page 23 of 46
Set this to Yes when gateway is behind firewall on a private network.
DTMF METHODS
DTMF Settings are in FXS portX/ProfileX page.
 DTMF in-audio
 DTMF via RTP (RFC2833)
 DTMF via SIP INFO
Set priority of DTMF methods according to your preference. This setting should be based on your server
DTMF setting.
PREFERRED VOCODER (CODEC)
The HT802 supports a broad range of voice codecs. Under Profile web pages, choose your preferred
order of different codecs:
 PCMU/A (or G711µ/a)
 G729 A/B
 G723.1
 G726 (16/24/32/40)
 iLBC
TABLE 7: BASIC SETTINGS
End User Password
Password to access the Web Configuration Menu. This field is case sensitive with a
maximum length of 25 characters.
Web Port
By default, HTTP uses port 80. This field is for customizable web port.
IP Address
There are two modes to operate the HT802:
dynamically assigned via DHCP: all the field values for the Static IP mode are not used
(even though they are still saved in the Flash memory.) The HT802 acquires its IP
address from the first DHCP server it discovers from the LAN it is connected.
Statically configured as: configure the IP address, Subnet Mask, Default Router IP
address.
DHCP hostname
Default is blank. This option specifies the name of the client. This field is optional but may
be required by some Internet Service Providers.
