CONFIGURING FOR WAVE

To successfully log in and use Wave, please see the following steps:

Step 1: From the UCM630X Web UI, navigate to the System Settings -> HTTP Server -> Wave Settings

section to configure External Host with the UCM630X’s public network address and retrieve/modify the

Wave Port information.

Step 2: Map the internal Wave port to an external port number on your router.

Figure 6: HTTP Server - Wave Settings

If properly configured, users should now be able to access the Wave login page via the public network

address and external port.

Table 3: Wave Settings

Wave Settings

External Host

Configure the URL and port (optional) used to access the Wave portal or UCM

meeting rooms if the UCM is behind NAT. If UCM RemoteConnect is used, this

field will be configured automatically.
