Grant GSD1 User Manual

Dimensions &
Fixing Intervals
11
3.3 In-Roof System Installation
Position of Mounting Rails
1-5 Solar Collectors, Horizontal, Side by Side
50
100
100
340
190
50
160 160
50
100
100
340
190
50
160 160
50
100
100
340
190
50
160 160
50
100
100
340
190
50
160
160
50
100
100
340
190
50
160 160
6525mm
8615mm
10700mm
1550mm 1550mm 1550mm
1550mm
2355mm
4440mm
Figure 17: 1 collector (landscape) Figure 18: 2 collectors (landscape)
Note: Dimensions include cover frame
Figure 20: 4 collectors (landscape)
Figure 19: 3 collectors (landscape)
Figure 21: 5 collectors (landscape)
1550mm
