Grant GSD1 User Manual

3 Dimensions & Fixing Intervals
10
Dimensions &
Fixing Intervals
3.3 In-Roof System Installation
Position of Mounting Rails
1-5 Solar Collectors, Vertical, Side by Side
3835mm
6215mm
5025mm
2645mm
2450mm
1460mm
50
100
100
340
190
50
160 160
50
100
100
340
190
50
160 160
50
100
100
340
190
50
160 160
50
100
100
340
190
50
160 160
50
100
100
340
190
50
160 160
2450mm
2450mm
2450mm
2450mm
Figure 13: 2 collectors (portrait)
Figure 14: 3 collectors (portrait)
Figure 16: 5 collectors (portrait)
Figure 15: 4 collectors (portrait)
Note: Dimensions include cover frame
Figure 12: 1 collector (portrait)
