Grant GSD1 User Manual

Dimensions &
Fixing Intervals
9
3.2 Flat-roof Installation
Position of Roof Anchors and Mounting Rails
60mm
1187mm
3561mm
5935mm
4748mm
2374mm
700mm* ~700mm
~1300mm
~1300mm ~1300mm ~1300mm =1200*
~1300mm ~1300mm =1200mm*=1200mm*
=700mm*
~500mm
~500mm
~500mm
~500mm
~500mm~500mm
~500mm~500mm~250mm~250mm
1770mm1770mm1770mm
1770mm
60
1770mm
2042mm 2042mm
2042mm
2042mm
1320mm 54mm
1318mm
1316mm
1334mm
2042mm
Figure 7: 1 collector (portrait) Figure 8: 2 collectors (portrait)
Figure 9: 3 collectors (portrait)
Figure 11: 5 collectors (portrait)
Figure 10: 4 collectors (portrait)
60mm
60mm 60mm
* This is a fixed dimension and must be as shown above
